SRT Streaming

Secure Reliable Transport (SRT) is a widely used protocol for transporting audio, video or arbitrary data streams over IP networks. It compensates for packet loss, jitter and fluctuating bandwidth while maintaining stream integrity and low latency.

SRT is particularly useful when transporting EIT streams securely over public or unmanaged IP networks — for example when the multiplexer is located at a remote uplink site.

cherryEPG does not generate SRT natively. Instead, the SRT stream is created using the external open-source tool srt-live-transmit, which relays the locally generated UDP multicast stream to a remote SRT destination.

This approach allows secure and reliable transport of EPG data without the need for VPN tunnels.

Follow the steps below as cherryepg user to implement a simple SRT relay on your cherryEPG installation.

1. Install the required SRT tools:

   sudo apt update
   sudo apt install srt-tools


   Verify installation:

   which srt-live-transmit


2. Setup the srt relay daemon by creating a systemd user service.

   Create the following file: /var/lib/cherryepg/.config/systemd/user/srt-relay.service

   and insert the content below:

   [Unit]
   Description=SRT Live Transmit Relay
   After=network-online.target
   Wants=ringelspiel.target

   [Service]
   Type=simple
   ExecStart=/usr/bin/srt-live-transmit udp://239.10.10.1:5500 \
     srt://<destination-ip>:<port>?mode=caller&latency=200&passphrase=<your-passphrase>
   Restart=always
   RestartSec=5

   [Install]
   WantedBy=default.target


3. Adjust configuration parameters and modify the following values according to your setup:

   • <destination-ip>:<port> → IP address and port of the remote multiplexer (SRT listener)
   • <your-passphrase> → Encryption passphrase for SRT
   • 239.10.10.1:5500 → Multicast address and port defined in your cherryEPG scheme

4. Enable and start the service by running the following command as cherryepg user:

   systemctl --user daemon-reload
   systemctl --user enable srt-relay.service
   systemctl --user start srt-relay.service


   You can check the service status with:

   systemctl --user status srt-relay.service


   or get live logs:

   systemctl --user status srt-relay.service


   You should see connection establishment messages and packet counters.

5. Configure listener mode on the multiplexer and make sure the firewall allows the configured SRT port.

   If authentication fails, verify that the passphrase matches on both sides.
